Main Characteristics

1.Shaftless hydraulic unwinding, precise correction & stable feeding
2.Imported bearing drive, quiet, durable and adjustable width
3.VFD synchronous traction, steel-rubber roller high-efficiency drive
4.Precise round knife slitting, burr-free neat cutting
5.Dual-shaft rewinding, static elimination & auto diameter measurement
6.PLC intelligent control, high automation and labor saving

Specifications

Model CX-FQ.Z 1300 CX-FQ.Z 1600
Max. Width of raw material 1300mm 1600mm
Max. Diameter of raw material Φ1200mm Φ1200mm
Max. Diameter of rewinding Φ800mm Φ800mm
Slitting speed 400m/min 400m/min
Min. Slitting Width 50mm 50mm
Machine Weight  4500kg 5000kg
Total Power 40kw 45kw
Overall Dimension(L*W*H) 4600*3800*2250mm 4600*4100*2250mm
